PREMIUM EXTRA
Five-axis laser cutting machine for large work pieces
The PREMIUM EXTRA five-axis laser machine is designed for cutting stainless and heat-resistant steel, high-hardness steel, and non-ferrous metals.
It has 5 interpolated axes, and the software synchronizes the operation of all axes, laser and optical head.
- The size of the workpiece can be up to 1055 mm in diameter, up to 880 mm in height
- Equipped with a roll-out work table with a precision rotary table at the end — for convenient and accurate positioning of the workpiece
- Enclosed area for working with workpieces and equipment - for semi-automatic loading and unloading
- The machine is equipped with cabinet protection for the safety of operating personnel and noise insulation
- Additional front door for access to small workpieces and machine service
- Remote operator console
Filter ventilation unit
Video measuring system
Compressor
| Radiation source | Fiber laser (IPG Photonics) |
| Overall dimensions of the workpiece, mm | Diameter up to 1055, height up to 880 |
| Roughness of machined surfaces | Ra 6.3 |
| Drives | HIWIN |
| Optical head tilt range, ° | ±135° |
| Optical head rotation range, ° | ±540° |
| Rotary table diameter, mm | 600 |
| Processed sheet materials | Brass, stainless steel, heat-resistant steel, high-hardness steel, black steel, copper, aluminum alloys, gold, titanium, diamond-coated materials, ceramics, paronite, polycor (alumina ceramic), glass-ceramic (sitall) |
| Source power | 150/1500; 300/3000 |
| Workpiece wall thickness, mm | up to 5 |
