The laser operates in pulsed mode. It has a high power of laser radiation per pulse with the efficiency of converting pump radiation into laser radiation.
Applications: laser cutting, welding and engraving, heat treatment of metals, additive technologies, communication systems.
| Radiation wavelength, µm | 1060–1080 |
| Optical power of generated laser radiation, W, min | 20000–50000 |
| Output power adjustment range, % | 10–100 |
| Beam quality parameter, BPP, mm·mrad | |
| Output fiber core diameter, µm | |
| Optical power rise/fall time, µs max (10 to 95%, 95 to 10%) | 50 |
| Optical connector type | |
| Laser operating mode | CW, modulated |
| Maximum modulation frequency, kHz | 5 |
| Power supply, Hz | 3-phase, 50/60 Hz, 400–480 |
| Power consumption, kW | 67–167 |
| Weight, kg | до 1600 |
| Overall dimensions, mm | |
| Pilot laser wavelength, nm | 630–660 |
| Control interfaces | RS-232, Ethernet, analog |
| Cooling type | Water |
| Operating temperature, °C | 15 ~ 35 |
| Humidity, % | до 70 |
| Storage temperature |
